2.7mm Volar Angular Plate
Product Over View
The 2.4mm AV-Wiselock Distal Radius and Volar Rim system is
locking plate system for volar distal radius fracture, providing
optimal fit for radius bone. The system provides anatomically
designed low-profile plates that resist angular collapse and
function as an effective fracture reduction aid.
The system comprises an Instrumentation set featuring standard instruments for surgery that helps Distal Radius Volar Rim System efficient and easy to use.
Products Features
- Precontoured plates for an anatomical fit.
- Narrow, Standard and wide plate head options for optimal fit
- Different distal width designs for better fit to individual anatomy.
- Left/right-specific
- Provides sufficient rigidity and stable locking.
- Locking/non-locking option in all screw holes
- Variable angle screw locking mechanism up to ±15°
- Window for fracture line position
- Guide pin holes for temporary plate fixation.
- Aiming Arm block for accurate drilling angle Volar Distal Radius
- Locking Plate – Volar Rim Type
2.4mm AV-Wiselock Distal Radius and Volar Rim System is indicated for displaced extra-articular and intra-articular distal radius fracture and
corrective osteotomies of the distal radius.
